MBT-100X2.5X1.25
MBT Metric PTFE Solid Back-Up Ring, 100.00 X 2.50 X 1.25
Part #:
MBT-100X2.5X1.25
Min. Order Qty: 1
Brand: HPSI
HPSI
Metric PTFE Back-Up Rings are made from virgin PTFE to provide excellent chemical resistance and high-temperature performance for demanding sealing applications. Designed for use with metric O-rings, these back-up rings help prevent extrusion in high-pressure applications. The S suffix designates a split design for easier installation, G designates glass-filled PTFE for added strength, and B denotes bronze-filled PTFE for enhanced wear resistance.
| Construction | : | Solid |
| Inside Diameter | : | 100.00 mm |
| Material | : | PTFE |
| Outside Diameter | : | 105.00 mm |
| Part Number | : | (Prefix)(ID)X(C/S)X(TH) |
| Temperature Range | : | -40° to 500°F |
| Thickness | : | 1.25 mm |
| Width | : | 2.50 mm |
- Virgin PTFE construction provides excellent chemical resistance
- High-temperature performance supports demanding applications
- Designed for use with metric O-rings
- Helps prevent O-ring extrusion in high-pressure applications
- S suffix designates a split design for easy installation
- G suffix designates glass-filled PTFE for added strength
- B suffix designates bronze-filled PTFE for enhanced wear resistance
- Metric design provides compatibility with metric O-ring applications
